2022 Diamondback Haanjo 4
Shimano GRX400
2022 Diamondback Haanjo 4
$1,280.00 - Save $320.00
$1,280.00 - Save $320.00
$1,280.00 - Save $320.00
$1,280.00 - Save $320.00
$1,280.00 - Save $320.00
Key Features
- Wheel Size: 700c
- Frame Material: Aluminum
Specs
- Diamondback 6061 T-6 Aluminum frame
- Shimano GRX drivetrain
- Diamondback Monocoque Carbon fork
- HED Tomcat Disc Tubeless wheelset
- Shimano Tiagra Disc brakes
- WTB Riddler 700x37c front tire
- WTB Riddler 700x37c rear tire
- WTB Silverado saddle
Learn More About the 2022 Diamondback Haanjo 4
If you're ready to get serious about gravel riding, the 2022 Diamondback Haanjo 4 deserves a look. This bike is built around a 6061 T-6 aluminum frame that feels light, but is tough enough to take on the bumps and rocks of gravel roads.
Shifting gears comes easy thanks to the Shimano GRX groupset, which is designed specifically for gravel riding. You get a wide range of gears to power up steep climbs and plenty of options to keep your pace steady on flats. The GRX levers are ergonomic and make gear changes smooth and reliable, no matter the weather or trail conditions.
The ride quality takes a step up thanks to the Monocoque Carbon fork. Carbon helps soak up vibrations that can wear you down. It smooths out rough patches so your arms and shoulders don't get battered. Plus, the fork sheds some weight, helping the bike feel quick and precise when the trail gets technical.
Wheels matter when you're riding gravel, and the HED Tomcat Disc tubeless-ready set brings strength without a weight penalty. Being tubeless-ready means you can run lower tire pressures, which translates to better traction and a softer ride. These wheels strike a nice balance so you won't worry about dents or damage on rough terrain, but still get snappy acceleration.
Stopping power is crucial when trails get steep or tricky. The Shimano Tiagra hydraulic disc brakes on this bike deliver consistent, strong braking that you can modulate easily. Whether it's a wet descent or a loose corner, you'll find confidence in how these brakes handle.
The tires, WTB Riddler 700x37c, sit at a sweet spot. They're grippy enough on loose gravel yet efficient rolling on pavement. Their tread pattern handles a mix of surfaces well, making your route options wide open without needing a tire change each time.
Comfort isn't forgotten, with the WTB Silverado saddle offering solid support without bulk. Its shape keeps you positioned efficiently on the bike and the padding reduces pressure points that can distract on longer rides.
All told, the Haanjo 4 is ready for serious gravel riding, whether you're charging down fire roads, tackling country lanes, or mixing pavement with dirt trails.
Product Identifiers
- Barcode: 22983396
Product Identifiers
- Barcode: 45257444
Product Identifiers
- Barcode: 45290212
Product Identifiers
- Barcode: 45322980
Product Identifiers
- Barcode: 45355748
Geometry Data By Frame Size
Measurements primarily in millimeters (mm) unless otherwise noted.
| FRAME SIZE | SM/50 5'4"-5'8" | LG/56 5'10" - 6'1" | XS/47 5'1"-5'4" | MD/53 5'7"-5'10" | XL/59 6'1-6'4" |
|---|---|---|---|---|---|
| Bike Stand Over Height | 727.0 mm | 811.0 mm | 701.0 mm | 776.0 mm | 845.0 mm |
| Bike Seat Tube Length | 450.0 mm | 535.0 mm | 395.0 mm | 505.0 mm | 565.0 mm |
| Bike Top Tube Length | 525.0 mm | 560.0 mm | 525.0 mm | 545.0 mm | 580.0 mm |
| Bike Head Tube Length | 120.0 mm | 175.0 mm | 105.0 mm | 155.0 mm | 200.0 mm |
| Bike Head Angle | 70.0 ° | 72.0 ° | 70.0 ° | 72.0 ° | 72.0 ° |
| Bike Seat Angle | 75.0 ° | 73.5 ° | 75.0 ° | 73.5 ° | 73.5 ° |
| Bike Wheel Base | 1039.0 mm | 1041.0 mm | 1033.0 mm | 1041.0 mm | 1062.0 mm |
| Bike Chain Stay Length | 440.0 mm | 440.0 mm | 440.0 mm | 440.0 mm | 440.0 mm |
| Bike Fork Offset | 50.0 mm | 50.0 mm | 50.0 mm | 50.0 mm | 50.0 mm |
| Bike Bb Height | 280.0 mm | 280.0 mm | 280.0 mm | 280.0 mm | 280.0 mm |
| Bike Bb Drop | 70.0 mm | 70.0 mm | 70.0 mm | 70.0 mm | 70.0 mm |
| Bike Stack | 550.0 mm | 610.0 mm | 535.0 mm | 583.0 mm | 633.0 mm |
| Bike Reach | 377.0 mm | 379.0 mm | 380.0 mm | 367.0 mm | 392.0 mm |
| Bike Fork Length | 404.0 mm | 404.0 mm | 404.0 mm | 404.0 mm | 404.0 mm |
Detailed Specs By Build Kit
| FRAME | DB Alternative Road, Endurance Geometry, Relaxed Head Tube Angle, Fully Butted 6061-T6 Aluminum Formed Top Tube, Tapered Headtube, Flat Mount Disc , 142x12mm Thru-axle w/Replaceable Hanger |
|---|---|
| FORK | DB Gravel Performance, Full Monocoque Carbon, Carbon 12mm Thru Axle Drop Outs, Flat Mount Disc ready, w/Tapered Steerer Tube |
| HEADSET | FSA No.42, Sealed Cartridge |
| CRANKS | Shimano GRX 600, 46/30T |
| BOTTOM BRACKET | Shimano Outboard Bearing |
| FRONT DERAILLEUR | Shimano GRX400 31.8mm Band Clamp |
| REAR DERAILLEUR | Shimano GRX400, Shadow Plus, 10 Speed, GS |
| SHIFTER | Shimano Tiagra 10 Speed, Dual Control 2x10 Speed |
| COGSET | Shimano HG500 Cassette, 10 Speed, 11-34T |
| CHAIN | KMC X10EL, 10 Speed |
| FRONT HUB | 28h Aluminum Sealed Cartridge, Center Lock, 12mm Thru-axle |
| REAR HUB | 28h Aluminum Sealed Cartridge, Center Lock, 142x12mm Thru-axle, Cassette |
| SPOKES | 2.0/1.8/2.0 Butted Stainless Steel |
| RIMS | HED Tomcat Disc, 28h, 21mm Internal Width, Taped for Tubeless |
| TIRES | WTB Riddler, Dual DNA Compound, 700x37c |
| BRAKE LEVERS | Shimano Tiagra |
| PEDALS | DB Resin Gravel Platform |
| HANDLEBAR | HED, 7050 Aluminum 12 Degree Flare, 31.8mm Bar Bore |
| GRIPS | Diamondback Endurance Gel Tape |
| STEM | HED, 6061 Aluminum 3D Forged, +/-7° Rise, 31.8 Bar Bore |
| SEAT | WTB Silverado Race |
| SEATPOST | HED, 6061 Aluminum 27.2mm |
| EXTRAS | Tool Kit, Chainstay Protector, Tubeless Compatible - Requires Tubeless Tire, Sealant, and Valves to complete (not included). |
| BRAKES | TRP Spyre C Flat Mount Mechanical Disc, w/160mm Front / 160mm Rear Rotors |
