2023 Norco Sight X0 Transmission Custom
X0 Transmission + Black Label Wheels
Buy it with
Key Features
- Wheel Size: 29"
- Front Travel: 160mm
- Rear Travel: 150mm
- Frame Material: Carbon
Specs
- Carbon All-Mountain, Aluminum CS, 150mm Travel, 27.5" and 29" options, UDH, Hangerless Interface Compatible, Ride Aligned™ frame
- Rockshox Lyric Ultimate 160mm
- Fox Factory FLOAT X2, HSC/LSC, HSR/LSR, 185x52.5mm Trunnion shock
- SRAM X0 T-Type Pod Controller
- SRAM X0 T-Type Derailleur
- SRAM DUB Bottom Bracket
- SRAM X0 T-Type 10-52t cassette
- SRAM X0 T-Type Flattop chain
- SRAM X0 T-Type 170mm crankset
- Hayes Dominion A4 4-Piston brakes
- Reynolds Black Label Carbon Wheelset with I9 Hubs
- Vittoria Mazza 29x2.4 tires F+R
- One Up Carbon 35mm Rise handlebar
- One Up V2 34.9mm 210mm dropper seatpost
- Burgtec 50mm stem
- WTB Silverado saddle
Learn More About the 2023 Norco Sight X0 Transmission Custom
The 2023 Norco Sight X0 Transmission Custom is built to handle tough, technical trails without missing a beat. Its carbon frame, combined with aluminum chainstays, gives you a bike that feels both strong and nimble. You get 150mm of rear suspension travel that soaks up bumps while keeping your ride stable. Norco has included their Ride Aligned™ system, which fine-tunes the bike’s geometry based on your setup for better handling. You can pick either 27.5" or 29" wheels, depending on how you like to ride. Each option changes the bike’s feel in a noticeable way.
Up front, the RockShox Lyrik Ultimate fork provides 160mm of travel with adjustments for compression and rebound. It smooths out rough terrain, letting you charge downhill confidently. The Lyrik Ultimate is a versatile high-end fork with legendary performance. It features high tunability, a low friction design, a sturdy 35mm chassis, ButterCups that block 20% of high-frequency “trail chatter” vibrations, and a DebonAir+ air spring for a butterlike small bump feel. In the back, the Fox Factory FLOAT X2 shock gives you nuanced control over small bumps and big hits by adjusting high and low-speed compression and rebound settings. This keeps the rear suspension reactive without feeling harsh or wallowy.
Shifting gears is effortless with the SRAM X0 T-Type wireless drivetrain. It stays precise, no matter how hard you're pushing, which makes climbing steep or technical sections less stressful. The X0 T-Type Pod Controller puts smooth shifting control right at your fingertips. The combination of the X0 derailleur, a wide 10-52t cassette, and a Flattop chain means you have reliable gears ready for everything from slow climbs to fast descents. The SRAM DUB bottom bracket adds durability for aggressive pedaling and efficient power transfer.
When you need to stop or scrub speed, Hayes Dominion A4 four-piston brakes provide strong, controlled braking power. They modulate well so you can dial in your speed confidently on tricky or fast terrain.
The wheelset on this bike is no afterthought. You get Reynolds Black Label carbon wheels, which bring lightweight strength and responsive handling. Industry Nine hubs offer smooth rolling and durability. Vittoria Mazza tires sized 29x2.4" front and rear give you excellent grip and durability, whether the trail is rocky, loose, or muddy.
The cockpit setup is designed for both comfort and control. The OneUp Carbon handlebar has a 35mm rise for a comfortable position without sacrificing precision. Paired with a Burgtec 50mm stem, steering feels accurate and direct. The OneUp V2 dropper post offers 210mm of travel, allowing quick seat height changes that suit aggressive riding styles. The WTB Silverado saddle completes the setup with ergonomic support designed for long hours in the saddle.
This bike isn't just suited for one type of trail. It's ready for long climbs, rocky sections, and fast descents with confidence-inspiring performance at every turn. If you want a reliable, capable all-mountain rig that'll grow with your riding skills, the 2023 Norco Sight X0 Transmission Custom deserves a look.
Product Identifiers
- Barcode: 058817547683
Geometry Data By Frame Size
Measurements primarily in millimeters (mm) unless otherwise noted.
27.5" Wheels
Size | S | M | L | XL |
---|---|---|---|---|
Front Travel | 160 | 160 | 160 | 160 |
Rear Travel | 150 | 150 | 150 | 150 |
Reach | 425 | 455 | 485 | 515 |
Stack | 585 | 594 | 603 | 612 |
Head Tube Angle | 63.5 | 63.5 | 63.5 | 63.5 |
Fork Offset | 37 | 37 | 37 | 37 |
Seat Tube Length | 370 | 395 | 435 | 465 |
Effective Seat Tube Angle | 77 | 77.3 | 77.7 | 78 |
Rear Centre Length | 430 | 435 | 440 | 445 |
Bottom Bracket Drop | 15 | 15 | 15 | 15 |
Bottom Bracket Height | 342 | 342 | 342 | 342 |
Horizontal Top Tube | 560 | 588 | 617 | 645 |
Wheelbase | 1180 | 1220 | 1259 | 1299 |
Standover | 668 | 677 | 683 | 701 |
Head Tube Length | 100 | 110 | 120 | 130 |
Trail | 136 | 137 | 137 | 137 |
Recommended Seatpost Drop | 150 | 170 | 170 | 200 |
Maximum Post Insertion | 225 | 250 | 270 | 270 |
Stem Length | 40 | 40 | 40 | 40 |
Crank Length | 170 | 170 | 170 | 170 |
Tire Size | 2.35"-2.6" | 2.35"-2.6" | 2.35"-2.6" | 2.35"-2.6" |
Water Bottle Compatible | 1x620mL | 1x750mL | 1x750mL | 1x750mL |
29" Wheels
Size | S | M | L | XL |
---|---|---|---|---|
Front Travel | 160 | 160 | 160 | 160 |
Rear Travel | 150 | 150 | 150 | 150 |
Reach | 425 | 455 | 485 | 515 |
Stack | 603 | 612 | 621 | 630 |
Head Tube Angle | 64 | 64 | 64 | 64 |
Fork Offset | 42 | 42 | 42 | 42 |
Seat Tube Length | 370 | 395 | 435 | 465 |
Effective Seat Tube Angle | 77 | 77.3 | 77.7 | 78 |
Rear Centre Length | 430 | 435 | 440 | 445 |
Bottom Bracket Drop | 25 | 25 | 25 | 25 |
Bottom Bracket Height | 350 | 350 | 350 | 350 |
Horizontal Top Tube | 564 | 593 | 621 | 649 |
Wheelbase | 1183 | 1222 | 1262 | 1301 |
Standover | 682 | 687 | 704 | 726 |
Head Tube Length | 90 | 100 | 110 | 120 |
Trail | 136 | 136 | 136 | 136 |
Recommended Seatpost Drop | 150 | 170 | 170 | 200 |
Maximum Post Insertion | 225 | 250 | 270 | 270 |
Stem Length | 40 | 40 | 40 | 40 |
Crank Length | 170 | 170 | 170 | 170 |
Tire Size | 2.35"-2.6" | 2.35"-2.6" | 2.35"-2.6" | 2.35"-2.6" |
Water Bottle Compatible | 1x620mL | 1x750mL | 1x750mL | 1x750mL |
Detailed Specs By Build Kit
KIT | A Frame Kit | C Frame Kit | A3 | A2 | A1 | C3 | C2 SRAM | C2 Shimano | C1 | C SE |
---|---|---|---|---|---|---|---|---|---|---|
FRAME | Aluminum All-Mountain, 150mm Travel, 27.5" and 29" Options, Ride Aligned™ | Sight carbon main frame and seatstay , 150mm travel | Aluminum All-Mountain, 150mm Travel, 27.5" and 29" Options, Ride Aligned™ | Aluminum All-Mountain, 150mm Travel, 27.5" and 29" Options, Ride Aligned™ | Aluminum All-Mountain, 150mm Travel, 27.5" and 29" Options, Ride Aligned™ | Carbon All-Mountain, Aluminum CS, 150mm Travel, 27.5" and 29" Options, Ride Aligned™ | Carbon All-Mountain, Aluminum CS, 150mm Travel, 27.5" and 29" Options, Ride Aligned™ | Carbon All-Mountain, Aluminum CS, 150mm Travel, 27.5" and 29" Options, Ride Aligned™ | Carbon All-Mountain, Aluminum CS, 150mm Travel, 27.5" and 29" Options, Ride Aligned™ | Carbon All-Mountain, Aluminum CS, 150mm Travel, 27.5" and 29" Options, Ride Aligned™ |
FORK | - | - | RockShox Yari RC, Motion Control, 160mm, 37mm Offset (27.5), 44mm Offset (29) | Fox FLOAT 36 Rhythm, 160mm, Sweep Adjust, 37mm Offset (27.5), 44mm Offset (29) | RockShox Lyrik Ultimate, Charger 2 RC2, 160mm, 37mm Offset (27.5), 44mm Offset (29) | RockShox Lyrik Select, Charger RC, 160mm, 37mm Offset (27.5), 44mm Offset (29) | RockShox Lyrik Ultimate, Charger 2 RC2, 160mm, 37mm Offset (27.5), 44mm Offset (29) | Fox Performance Elite 36, GRIP 2, 160mm, HSC, LSC, HSR, LSR, 37mm Offset (27.5), 44mm Offset (29) | RockShox Lyrik Ultimate, Charger 2 RC2, 160mm, 37mm Offset (27.5), 44mm Offset (29) | Fox Factory FLOAT 36, GRIP 2, 160mm, HSC/LSC/LSR |
REAR SHOCK | RockShox Super Deluxe Ultimate DH, LINM Tune, Meg Neg Air Can, 185x52.5mm Trunnion | Fox Factory FLOAT X2, HSC/LSC, HSR/LSR, 185x52.5 Trunnion | RockShox Super Deluxe Select R, LINM Tune, 185x52.5mm Trunnion | Fox Performance Float X2, LSC, LSR, 185x52.5mm Trunnion | RockShox Super Deluxe Ultimate DH, LINM Tune, Meg Neg Air Can, 185x52.5mm Trunnion | RockShox Super Deluxe Ultimate DH, LINM Tune, Meg Neg Air Can, 185x52.5mm Trunnion | RockShox Super Deluxe Ultimate DH, LINM Tune, Meg Neg Air Can, 185x52.5mm Trunnion | Fox Performance FLOAT X2, HSC/LSC, HSR/LSR, 185x52.5mm Trunnion | RockShox Super Deluxe Ultimate DH, LINM Tune, Meg Neg Air Can, 185x52.5mm Trunnion | Fox Factory FLOAT X2, HSC/LSC, HSR/LSR, 185x52.5mm Trunnion |
REAR SHIFTER | - | Shimano Deore SL-M6100-R | Shimano SLX SL-M7100-R | SRAM GX Eagle | Shimano Deore SL-M6100-R | SRAM GX Eagle | Shimano XT SL-M8100 | SRAM X0 Eagle | SRAM EA AXS 12 RH Rocker Controller | |
REAR DERAILLEUR | - | - | Shimano Deore RD-M6100 | Shimano SLX RD-M7100 | SRAM GX Eagle | Shimano Deore RD-M6100 | SRAM GX Eagle | Shimano XT RD-M8100 | SRAM XO1 Eagle | SRAM X01 Eagle AXS |
CRANKSET | - | - | Shimano Deore FC-MT6120-1, 32T, 170mm | Shimano SLX FC-M7100, 34T (27.5), 32T (27.5 S), 32T (29), 170mm | SRAM GX Eagle, 34T (27.5), 32T (27.5 S), 32T (29), 170mm | Shimano Deore FC-MT6120-1, 32T, 170mm | SRAM GX Eagle DUB, 34T (27.5), 32T (27.5 S), 32T (29), 170mm | Shimano Deore XT FC-M8120-1, 34T (27.5), 32T (27.5 S), 32T (29), 170mm | SRAM GX Eagle DUB, 34T (27.5), 32T (27.5 S), 32T (29), 170mm | SRAM Truvativ Decendent Carbon, 34T (27.5), 32T (27.5 S), 32T (29), 170mm |
BOTTOM BRACKET | - | - | Shimano Sealed Bearing, BSA Threaded | Shimano Sealed Bearing, BSA | Sealed Bearing DUB, BSA | Shimano PF92 | SRAM DUB PF92 | Shimano PF92 | SRAM DUB PF92 | SRAM DUB PF92 |
CHAIN TENSIONER | - | - | GW 1x Flip Guide | e*thirteen Vario Top Guide | e*thirteen Vario Top Guide, DMB | e*thirteen Vario Top Guide | e*thirteen Vario Top Guide | e*thirteen Vario Top Guide | e*thirteen Vario Top Guide, DMB | e*thirteen Vario Top Guide, DMB |
CASSETTE | - | - | Shimano Deore CS-M6100-12, 10-51T, 12 Speed | Shimano SLX CS-M7100-12, 10-51T, 12 Speed | SRAM Eagle XG 1275, 10-52T | Shimano Deore CS-M6100-12, 10-51T, 12 Speed | SRAM Eagle XG 1275, 10-52T | Shimano SLX CS-M7100-12, 10-51T, 12 Speed | SRAM Eagle XG 1275, 10-52T | SRAM Eagle XG 1295, 10-52T |
CHAIN | - | - | Shimano Deore CN-M6100 | Shimano Deore CN-M6100 | SRAM Eagle | Shimano Deore CN-M6100 | SRAM Eagle | Shimano SLX CN-M7100 | SRAM Eagle | SRAM Eagle |
FRONT BRAKE | - | - | Shimano Deore BR-MT420, 4 Piston, Metallic Pads | Shimano BR-MT520, 4 Piston, Metallic Pads | SRAM Code RSC, 4 Piston, Metallic Pads | Shimano BR-MT520, 4 piston, Metallic Pads | SRAM Code RSC, 4 Piston, Metallic Pads | Shimano SLX 4 piston, Metallic Pads | SRAM Code RSC, 4 Piston, Metallic Pads | SRAM Code RSC, 4 Piston, Metallic Pads |
FRONT BRAKE ROTOR | - | - | Shimano RT-64, 203mm | Shimano RT-64, 200mm | SRAM CenterLine, 200mm | Shimano RT-64, 203mm | SRAM CenterLine, 200mm | Shimano RT-64, 203mm | SRAM CenterLine, 200mm | SRAM CenterLine, 200mm |
REAR BRAKE | - | - | Shimano Deore BR-MT420, 4 Piston, Metallic Pads | Shimano BR-MT520, 4 Piston, Metallic Pads | SRAM Code RSC, 4 Piston, Metallic Pads | Shimano BR-MT520, 4 piston, Metallic Pads | SRAM Code RSC, 4 Piston, Metallic Pads | Shimano SLX 4 piston, Metallic Pads | SRAM Code RSC, 4 Piston, Metallic Pads | SRAM Code RSC, 4 Piston, Metallic Pads |
REAR BRAKE ROTOR | - | - | Shimano RT-64, 180mm | Shimano RT-64, 180mm | SRAM CenterLine, 180mm | Shimano RT-64, 180mm | SRAM CenterLine, 180mm | Shimano RT-64, 180mm | SRAM CenterLine, 180mm | SRAM CenterLine, 180mm |
BRAKE LEVERS | - | - | Shimano Deore BR-MT420 | Shimano BR-MT520 | SRAM Code RSC | Shimano BR-MT520 | SRAM Code RSC | Shimano SLX | SRAM Code RSC | SRAM Code RSC |
HANDLEBAR | - | - | Butted 6061 Alloy, 800mm, 25mm Rise | Butted 6061 Alloy, 800mm, 25mm Rise | Deity Ridgeline, 800mm, 25mm Rise | Butted 6061 Alloy, 800mm, 25mm Rise | Deity Ridgeline, 800mm, 25mm Rise | Deity Ridgeline, 800mm, 25mm Rise | Deity Ridgeline, 800mm, 25mm Rise | OneUp Carbon, 800mm, 20mm Rise |
STEM | - | - | Alloy, 40mm Length, 35mm Clamp | e*thirteen Base, 40mm Length, 35mm Clamp | Alloy, 40mm Length, 35mm Clamp | Alloy, 40mm Length, 35mm Clamp | Alloy, 40mm Length, 35mm Clamp | Alloy, 40mm Length, 35mm Clamp | Alloy, 40mm Length, 35mm Clamp | Norco CNC, 40mm Length. 35mm Clamp |
SEATPOST | - | - | TranzX YS105, Adjustable Travel, 34.9mm, 150mm (S), 170mm (M), 200mm (L, XL) | TranzX YS105, Adjustable Travel, 34.9mm, 150mm (S), 170mm (M), 200mm (L, XL) | OneUp Adjustable Dropper, 34.9mm, 150mm (S), 180mm (M, L), 210 (XL) | TranzX YS105, Adjustable Travel, 34.9mm, 150mm (S), 170mm (M), 200mm (L, XL) | TranzX YS105, Adjustable Travel, 34.9mm, 150mm (S), 170mm (M), 200mm (L, XL) | TranzX YS105, Adjustable Travel, 34.9mm, 150mm (S), 170mm (M), 200mm (L, XL) | OneUp Adjustable Dropper, 34.9mm, 150mm (S), 180mm (M, L), 210 (XL) | OneUp Adjustable Dropper, 34.9mm, 150mm (S), 180mm (M, L), 210 (XL) |
HEADSET | - | - | FSA #57 E Sealed Bearing, Tapered | FSA #57 E Sealed Bearing, Tapered | FSA #57 E Sealed Bearing, Tapered | FSA #57 E Sealed Bearing, Tapered | FSA #57 E Sealed Bearing, Tapered | FSA #57 E Sealed Bearing, Tapered | FSA #57 E Sealed Bearing, Tapered | FSA #57 E Sealed Bearing, Tapered |
SADDLE | - | - | WTB Volt 250 Sport | SDG Bel Air V3 | Fizik Alpaca Terra, Wingflex | SDG Bel Air V3 | SDG Bel Air V3 | SDG Bel Air V3 | Fizik Alpaca Terra, Wingflex | Fizik Alpaca Terra, Wingflex |
GRIPS | - | - | SDG Thrice Lock-On, Thin (S, M), Thick (L, XL) | SDG Thrice Lock-On, Thin (S, M), Thick (L, XL) | DMR DeathGrip Soft, Thin (S, M), Thick (L, XL) | SDG Thrice Lock-On, Thin (S, M), Thick (L, XL) | DMR DeathGrip Soft, Thin (S, M), Thick (L, XL) | DMR DeathGrip Soft, Thin (S, M), Thick (L, XL) | DMR DeathGrip Soft, Thin (S, M), Thick (L, XL) | DMR DeathGrip Soft, Thin (S, M), Thick (L, XL) |
SEATPOST CLAMP | Norco design alloy nutted clamp 38.5mm | Norco design alloy nutted clamp 38.5mm | Norco design alloy nutted clamp 38.5mm | Norco design alloy nutted clamp 38.5mm | Norco design alloy nutted clamp 38.5mm | Norco design alloy nutted clamp 38.5mm | Norco design alloy nutted clamp 38.5mm | Norco design alloy nutted clamp 38.5mm | Norco design alloy nutted clamp 38.5mm | Norco design alloy nutted clamp 38.5mm |
FRONT HUB | - | Shimano HB-MT410 15x110mm Boost, Center Lock | Shimano SLX 15x110mm Boost, Center Lock | DT Swiss 350, 15x110mm Boost, 6 Bolt | Shimano HB-MT410, 15x110mm Boost, Center Lock | DT Swiss 370, 15x110mm Boost, 6 Bolt | Shimano SLX M7010, 15x110mm Boost, Center Lock | DT Swiss 350, 15x110mm Boost, 6 Bolt | DT Swiss 240, 15x110mm Boost, 6 Bolt | |
REAR HUB | - | - | Shimano FH-MT510, 12x148mm Boost, Micro Spline, Center Lock | Shimano SLX, 12x148mm Boost, Micro Spline, Center Lock | DT Swiss 350, 12x148mm Boost, XD, 6 Bolt, 36T Engagement | Shimano FH-MT510, 12x148mm Boost, Micro Spline, Center Lock | DT Swiss 370, 12x148mm Boost, XD, 6 Bolt | Shimano SLX M7110, 12x148m Boost, Micro Spline, Center Lock | DT Swiss 350, 12x148mm Boost, XD, 6 Bolt | DT Swiss 240, 12x148mm Boost, XD, 6 Bolt |
REAR HUB SKEWER | Norco 12mm TA alloy w/allen key | Norco 12mm TA alloy w/allen key | - | - | - | - | - | - | - | - |
RIMS | - | - | WTB ST I30 TCS 2.0, 32H | Stan's Flow D, 32H | Stan's Flow S2, 32H | Stan's Flow D, 32H | Stan's Flow S2, 32H | Stan's Flow S2, 32H | DT Swiss M1700 Wheelset | |
FRONT TIRE | - | - | Maxxis Assegai 2.5" 3C Maxx Terra/EXO+/TR, Folding | Maxxis Assegai 2.5" 3C Maxx Terra/EXO+/TR, Folding | Maxxis Assegai 2.5" 3C Maxx Terra/EXO+/TR, Folding | Maxxis Assegai 2.5" 3C Maxx Terra/EXO+/TR, Folding | Maxxis Assegai 2.5" 3C Maxx Terra/EXO+/TR, Folding | Maxxis Assegai 2.5" 3C Maxx Terra/EXO+/TR, Folding | Maxxis Assegai 2.5" 3C Maxx Terra/EXO+/TR, Folding | DT Swiss XMC 1501 Carbon Wheelset |
REAR TIRE | - | - | Maxxis Minion DHR II 2.4" WT 3C, Maxx Terra/EXO+/TR, Folding | Maxxis Minion DHR II 2.4" WT 3C, Maxx Terra/EXO+/TR, Folding | Maxxis Minion DHR II 2.4" WT 3C, Maxx Terra/EXO+/TR, Folding | Maxxis Minion DHR II 2.4" WT 3C, Maxx Terra/EXO+/TR, Folding | Maxxis Minion DHR II 2.4" WT 3C, Maxx Terra/EXO+/TR, Folding | Maxxis Minion DHR II 2.4" WT 3C, Maxx Terra/EXO+/TR, Folding | Maxxis Minion DHR II 2.4" WT 3C, Maxx Terra/EXO+/TR, Folding | Maxxis Assegai 2.5" 3C Maxx Terra/EXO+/TR, Folding |
SPOKES/NIPPLES | - | - | Stainless, Black | Stainless, Black | DT Swiss Competition DB Stainless Black | Stainless Black | DT Competition DB Stainless Black | DT Competition DB Stainless, Black | DT Swiss | Maxxis Minion DHR II 2.4" WT 3C, Maxx Terra/EXO+/TR, Folding |
VALVES | - | - | WTB Tubeless Presta | Stan's 35mm Tubeless Presta | Stan's 35mm Tubeless Presta | Stan's 35mm Tubeless Presta | Stan's 35mm Tubeless Presta | Stan's 35mm Tubeless Presta | DT Swiss Tubeless Presta | DT Swiss |
SEALANT | - | - | Stan's - 200ml | Stan's - 200ml | Stan's - 200ml | Stan's - 200ml | Stan's - 200ml | Stan's - 200ml | Stan's - 200ml | We Are One |
PRICE | $1,999 | $3,499 | $3,499 | $4,399 | $5,699 | $5,199 | $6,199 | $6,299 | $7,099 | $9,999 |
