2025 Yeti ASR C3 GX AXS Transmission
Carbon Frame + SRAM GX Eagle AXS Transmission + RockShox SID Select+
Buy it with
2025 Yeti ASR C3 GX AXS Transmission
$6,600.00
$6,600.00
$6,600.00
$6,600.00
$6,600.00
Key Features
- Wheel Size: 29"
- Front Travel: 120mm
- Rear Travel: 115mm
- Frame Material: Carbon
Specs
- RockShox SID Select, 3-position compression lever fork
- RockShox SIDLuxe Select+, 3-position compression lever, 190mm length x 40mm stroke shock
- Cane Creek 40, integrated, 41mm upper, 52mm lower headset
- Burgtec Ride Wide Alloy Enduro, 760mm width, 35mm handlebar
- Burgtec Enduro MK3, 50mm stem
- SRAM G2 R, 4-piston brakes, SRAM CenterLine rotors (180mm front, 160mm rear)
- SRAM AXS POD Controller
- SRAM GX Eagle AXS Transmission rear derailleur
- SRAM GX Eagle Transmission Flattop chain
- SRAM GX Eagle Transmission 32T 170mm crankset
- SRAM GX Eagle, 32 tooth chainring
- SRAM DUB, 73mm English/BSA threaded bottom bracket
- SRAM GX Eagle Transmission 10-52 cassette
- DT Swiss M 1900 wheelset, 15mm x 110mm (Boost) front, 12mm x 148mm (Boost) with XD driver
- Maxxis Rekon, 3C MaxxTerra compound, EXO casing, TR, 29" x 2.4" front tire
- Maxxis Rekon Race, Dual compound, EXO casing, TR, 29" x 2.35" rear tire
- WTB Solano, chromoly rails saddle
- FOX Transfer SL Performance Elite dropper seatpost
Learn More About the 2025 Yeti ASR C3 GX AXS Transmission
The 2025 Yeti ASR C3 GX AXS Transmission is a purpose-built cross-country race machine that blends Yeti’s legendary ride quality with modern componentry for uncompromising performance on fast, technical terrain. Lightweight, responsive, and equipped with cutting-edge wireless shifting, this bike is engineered for riders chasing podiums or anyone who craves a lightning-quick trail experience.
At its core, the ASR C3 is designed around progressive XC geometry and Yeti’s renowned carbon frame construction, giving you a balance of stiffness and compliance that maximizes efficiency while keeping handling razor-sharp. The frame runs a 73mm BSA threaded bottom bracket for durability and serviceability, while the compact suspension platform is optimized for efficiency with a RockShox SIDLuxe Select+ shock (190x40mm) delivering supple small-bump sensitivity and effective pedaling support. Paired with a RockShox SID Select fork with 3-position compression control, the bike provides 120mm of front travel and 115mm rear—just the right amount for today’s demanding XC courses.
The drivetrain is centered on the new SRAM GX Eagle AXS Transmission, bringing flawless wireless shifting, incredible durability, and a simplified setup. A GX Eagle AXS Transmission derailleur works seamlessly with the GX Eagle Flattop chain, 32T crankset, and a massive 10-52T cassette, ensuring lightning-fast gear changes and the range needed for both all-out sprints and brutal climbs. The AXS Pod Controller keeps shifting intuitive, precise, and customizable.
For braking power, the ASR C3 comes equipped with SRAM G2 R 4-piston brakes paired with SRAM CenterLine rotors (180mm front, 160mm rear), giving you XC weight savings with trail-worthy stopping performance.
Wheel duties are handled by the reliable DT Swiss M 1900 wheelset, built on Boost spacing for stiffness and durability. Wrapped in Maxxis Rekon 29x2.4” (front) and Maxxis Rekon Race 29x2.35” (rear) tires with EXO casing and tubeless-ready construction, the setup provides a perfect mix of traction and speed on varied XC terrain.
Contact points are dialed for comfort and control: a Burgtec Ride Wide Alloy Enduro handlebar (760mm, 35mm clamp) paired with a Burgtec Enduro MK3 50mm stem ensures precise handling, while a WTB Solano saddle with chromoly rails balances lightweight efficiency with long-ride comfort. A FOX Transfer SL Performance Elite dropper post keeps the bike versatile, offering on-the-fly saddle height adjustments without compromising XC weight priorities.
Every detail on the Yeti ASR C3 GX AXS Transmission is built for speed and reliability, from the smooth Cane Creek 40 headset to the rider-focused cockpit. The result is a race-ready XC bike that thrives in the heat of competition while remaining capable and fun on fast-flowing singletrack.
The 2025 Yeti ASR C3 GX AXS Transmission delivers cutting-edge carbon XC performance with wireless shifting, lightweight suspension, and race-ready geometry—perfect for riders chasing speed without compromise.
Geometry Data By Frame Size
Measurements primarily in millimeters (mm) unless otherwise noted.
| SIZE | XS | S | M | L | XL |
|---|---|---|---|---|---|
| SEAT TUBE LENGTH | 400 | 410 | 430 | 470 | 495 |
| EFFECTIVE TOPTUBE LENGTH | 554 | 574 | 600 | 610 | 630 |
| HEADTUBE ANGLE | 66.5 | 66.5 | 66.5 | 66.5 | 66.5 |
| EFF. SEAT TUBE ANGLE | 75.5 | 75.5 | 75.5 | 75.5 | 75.5 |
| ACTUAL SEAT TUBE ANGLE | 70.4 | 70.8 | 71.2 | 71.6 | 72.1 |
| CHAINSTAY LENGTH | 433 | 435 | 437 | 439 | 441 |
| WHEELBASE | 1122 | 1144 | 1174 | 1201 | 1236 |
| ESTIMATED BB HEIGHT | 335 | 335 | 335 | 335 | 335 |
| STANDOVER | 768 | 768 | 771 | 771 | 776 |
| HEADTUBE LENGTH | 92 | 92 | 101 | 111 | 133 |
| AXLE TO CROWN | 531 | 531 | 531 | 531 | 531 |
| OFFSET | 44 | 44 | 44 | 44 | 44 |
| STACK | 592 | 592 | 600 | 610 | 630 |
| REACH | 400 | 420 | 445 | 465 | 490 |
| FRONT CENTER | 689 | 709 | 737 | 762 | 795 |
| VERTICAL FORK TRAVEL | 110 | 110 | 110 | 110 |
Detailed Specs By Build Kit
| BUILD | T5 ULT XX SL TRANSMISSION | T3 X0 TRANSMISSION | T4 XX1 TURQ | T2 TURQ | C3 GX TRANSMISSION | C2 | FRAME ONLY |
|---|---|---|---|---|---|---|---|
| DETAILS | TURQ Carbon Frame, 120mm SID ULT Flight Attendant and SIDLUXE Flight Attendant, SRAM XX SL T-Type with Power Meter and LEVEL ULT Brakes | TURQ Carbon Frame, 120mm SID ULT 3P and SIDLUXE ULT 3p with Twistloc ULT, SRAM X0 T-Type and LEVEL TLM Brakes | TURQ Carbon Frame, 120mm SID ULT 3P and SIDLUXE ULT 3p with Twistloc ULT, SRAM XX1 and LEVEL TLM Brakes | TURQ Carbon Frame, 120mm SID ULT 3P & SIDLUXE ULT 3p with Twistloc ULT, SRAM X01 Eagle & LEVEL TLM Brakes | C/Series Carbon Frame, 120mm SID 3P and SIDLUXE SELECT+ 3p, SRAM GX T-Type and LEVEL TL Brakes | C/Series Carbon Frame, 120mm SID 3P and SIDLUXE SELECT+ 3p, SRAM GX Eagle and LEVEL TL Brakes | T-Series Carbon Frame, SIDLUXE ULT 3p with Twistloc ULT |
| FRAME | TURQ Series carbon fiber frame, threaded bottom bracket, 148mm x 12mm BOOST dropouts, integrated derailleur hanger and axle | TURQ Series carbon fiber frame, threaded bottom bracket, configurable cable ports, 148mm x 12mm BOOST dropouts, integrated derailleur hanger and axle | TURQ Series carbon fiber frame, threaded bottom bracket, configurable cable ports, 148mm x 12mm BOOST dropouts, integrated derailleur hanger and axle | TURQ Series carbon fiber frame, threaded bottom bracket, configurable cable ports, 148mm x 12mm BOOST dropouts, integrated derailleur hanger and axle | C/Series carbon fiber frame, threaded bottom bracket, configurable cable ports, 148mm x 12mm BOOST dropouts, integrated derailleur hanger and axle. | C/Series carbon fiber frame, threaded bottom bracket, configurable cable ports, 148mm x 12mm BOOST dropouts, integrated derailleur hanger and axle. | TURQ Series carbon fiber frame, threaded bottom bracket, configurable cable ports, 148mm x 12mm BOOST dropouts, integrated derailleur hanger and axle |
| FORK | ROCK SHOX SID ULTIMATE FLIGHT ATTENDANT 120MM | ROCK SHOX SID ULTIMATE 3P REMOTE 120MM | ROCK SHOX SID ULTIMATE 3P REMOTE 120MM | ROCK SHOX SID ULTIMATE 3P REMOTE 120MM | ROCK SHOX SID SELECT 3P 120MMUPGRADABLE | ROCK SHOX SID SELECT 3P 120MMUPGRADABLE | |
| MATERIAL | TURQ SERIES | TURQ SERIES | TURQ SERIES | TURQ SERIES | C/SERIES | C/SERIES | TURQ SERIES |
| WEIGHT | 22.97 | 24.3 | 23.58 | 24.04 | 26.02 | 25.8 | 4.03 |
| TRAVEL | 115MM (4.5") | 115MM (4.5") | 115MM (4.5") | 115MM (4.5") | 115MM (4.5") | 115MM (4.5") | 115MM (4.5") |
| REAR SHOCK | ROCK SHOX SIDLUXE ULTIMATE FLIGHT ATTENDANT | ROCK SHOX SIDLUXE ULTIMATE 3P REMOTE | ROCK SHOX SIDLUXE ULTIMATE 3P REMOTE | ROCK SHOX SIDLUXE ULTIMATE 3P REMOTE | ROCK SHOX SIDLUXE SELECT + 3pUPGRADABLE | ROCK SHOX SIDLUXE SELECT + 3pUPGRADABLE | ROCK SHOX SIDLUXE ULTIMATE 3P REMOTE |
| WHEELSET | DT SWISS XRC 1200 SPLINE 30MM | DT SWISS XM1700 30MMUPGRADABLE | DT SWISS XM1700 30MMUPGRADABLE | DT SWISS XM1700 30MMUPGRADABLE | DT SWISS M1900 30MM | DT SWISS M1900 30MM | |
| REAR DER | SRAM XX SL EAGLE AXS TRANSMISION | SRAM X0 EAGLE AXS TRANSMISSION | SRAM XX1 EAGLE | SRAM X01 EAGLE | SRAM GX EAGLE AXS TRANSMISSION | SRAM GX EAGLE | |
| SHIFT | SRAM AXS POD CONTROLLER | SRAM AXS POD CONTROLLER | SRAM XX1 EAGLE | SRAM X01 EAGLE | SRAM AXS POD CONTROLLER | SRAM GX EAGLE | |
| CRANK | SRAM XX SL TRANSMISSION 32T 170MM POWER METER | SRAM X0 EAGLE TRANSMISSION 32T 170MM | SRAM XX1 EAGLE 32T 170MM | SRAM X1 EAGLE 32T 170MM | SRAM GX EAGLE TRANSMISSION 32T 170MM | SRAM GX EAGLE 32T 170MM | |
| BB | SRAM DUB BSA 73 | SRAM DUB BSA 73 | SRAM DUB BSA 73 | SRAM DUB BSA 73 | SRAM DUB BSA 73 | SRAM DUB BSA 73 | |
| CASSETTE | SRAM XX EAGLE SL TRANSMISSION 10-52 | SRAM X0 EAGLE TRANSMISSION 10-52 | SRAM XX1 EAGLE 1299 10-52 | SRAM X01 EAGLE 1295 10-52 | SRAM GX EAGLE TRANSMISSION 10-52 | SRAM GX EAGLE 1275 10-52 | |
| CHAIN | SRAM XX EAGLE SL TRANSMISSION FLATTOP | SRAM X0 EAGLE TRANSMISSION FLATTOP | SRAM XX1 EAGLE | SRAM GX EAGLE | SRAM GX EAGLE TRANSMISSION FLATTOP | SRAM GX EAGLE | |
| BRAKES | SRAM LEVEL ULTIMATE 2 PISTON | SRAM LEVEL TLM 2 PISTON | SRAM LEVEL TLM 2PISTON | SRAM LEVEL TLM 2 PISTON | SRAM LEVEL TL 2 PISTON | SRAM LEVEL TL 2 PISTON | |
| ROTORS | SRAM CENTERLINE X 180/SRAM CENTERLINE X 160 | SRAM CENTERLINE 180/SRAM CENTERLINE 160 | SRAM CENTERLINE 180/SRAM CENTERLINE 160 | SRAM CENTERLINE 180/SRAM CENTERLINE 160 | SRAM CENTERLINE 180/SRAM CENTERLINE 160 | SRAM CENTERLINE 180/SRAM CENTERLINE 160 | |
| POST | SRAM REVERB AXS 31.6MM / XS: 100MM, SM: 125MM, MD: 150MM LG-XL: 170MM | FOX TRANSFER SL FACTORY 31.6MM / XS-SM: 125MM, MD-XL: 150MM | FOX TRANSFER SL FACTORY 31.6MM / XS-SM: 125MM, MD-XL: 150MM | FOX TRANSFER SL PERFORMANCE ELITE 31.6MM / XS-SM: 125MM, MD-XL: 150MM | FOX TRANSFER SL PERFORMANCE ELITE 31.6MM / XS-SM: 125MM, MD-XL: 150MM | FOX TRANSFER SL PERFORMANCE ELITE 31.6MM / XS-SM: 125MM, MD-XL: 150MM | |
| FRONT TIRE | MAXXIS REKON 2.4 EXO | MAXXIS REKON 2.4 EXO | MAXXIS REKON 2.4 EXO | MAXXIS REKON 2.4 EXO | MAXXIS REKON 2.4 EXO | MAXXIS REKON 2.4 EXO | |
| REAR TIRE | MAXXIS REKON RACE 2.35 EXO | MAXXIS REKON RACE 2.35 EXO | MAXXIS REKON RACE 2.35 EXO | MAXXIS REKON RACE 2.35 EXO | MAXXIS REKON RACE 2.35 EXO | MAXXIS REKON RACE 2.35 EXO | |
| HEADSET | CANE CREEK 70 HELLBENDER LITE | CANE CREEK 70 HELLBENDER LITE | CANE CREEK 70 HELLBENDER LITE | CANE CREEK 70 HELLBENDER LITE | CANE CREEK 40 INTEGRATED | CANE CREEK 40 INTEGRATED | |
| BAR | RACE FACE NEXT SL 35X740 | RACE FACE NEXT SL 35X740 | RACE FACE NEXT SL 35X740 | RACE FACE NEXT SL 35X740 | BURGTEC RIDE WIDE ALLOY ENDURO 35X760MM | BURGTEC RIDE WIDE ALLOY ENDURO 35X760MM | |
| STEM | BIKE YOKE BARKEEPER 55MM | BIKE YOKE BARKEEPER 55MM | BIKE YOKE BARKEEPER 55MM | BIKE YOKE BARKEEPER 55MM | BURGTEC ENDURO MK3 35X50MM | BURGTEC ENDURO MK3 35X50MM | |
| GRIPS | ESI CHUNKY | SRAM TWISTLOC ULT 3P | SRAM TWISTLOC ULT 3P | SRAM TWISTLOC ULT 3P | ODI ELITE PRO | ODI ELITE PRO | |
| SEAT | SOLANO TITANIUM | SOLANO CHROMOLY SL | SOLANO TITANIUM | SOLANO CHROMOLY SL | SOLANO CHROMOLY SL | SOLANO CHROMOLY SL | |
| UPGRADES | DT Swiss XRC 1200 Carbon Wheelset +$2,000 | DT Swiss XRC 1200 Carbon Wheelset +$2,000 | DT Swiss XRC 1200 Carbon Wheelset +$2,000 | RockShox Ultimate Suspension with TwistLoc +$600 | RockShox Ultimate Suspension with TwistLoc +$600 | ||
| PRICE | $13,900 | $8,600 | $7,900 | $7,200 | $6,600 | $5,600 | $4,000 |
